COMEUP

DV-6s 12V CM

Was: $575.95
Now: $525.00
DV-6s 12V CM
SKU:
854754-CM

Description



  • Heavy duty series wound motor delivers superior torque output and faster line speed.

  • Lightweight and compact design is easy for front of vehicle.

  • Submersible sealed contactor handles high amps and allows higher duty cycle

  • 12 strand construction synthetic rope, Dyneema SK-75, coated to improve abrasion resistance and to protect from the ingress of dirt and grit.

  • The U.S Germany, U.K. France, etc patented automatic, full load cone brake structure outside the drum holds the full load without slippage.

  • Meet international standards of CE Machinery Directive 2006/42/CE, and CE Electromagnetic Compatibility Directive 2004/108/EC.



Specifications

Rated Line Pull 6,000 lb (2,722 kg) single line
Motor 3.2 hp/ 2,390 w 12V, series wound
Gear Ratio 3-stage planetary 216:1
Clutch (freespooling) Rotating Ring Gear
Brake (outside the drum) Automatic, full load CBS (Cone Brake Structure)
Winch construction Aluminum die cast housing with steel drum
Drum size 2.5" x 5.9" x 4.9" (63.5 x 151 x 125.5 mm)
Remote Control Waterproof remote w/ 17" cord
Rope Type Synthetic rope
Rope Size 21/64" x 80' (8 mm x 24.4 m)
Mounting Bolt Pattern 6" x 4.5" (152 x 114 mm)
Winch Weight 41.9 lb (19 kg)
Gross weight 47.6 lb (21.6 kg)
Box Dimension 19.9" x 8.3" x 13.4"( 505 x 210 x 340 mm)


Line Speed and Amp. Draw (1st layer of wire rope on the drum):

Line Pull,
kg / lb
Line Speed,
mpm / fpm
 Amp. Draw, A
12V
No Load 8.1 / 26.5 60
907 / 2,000 5.3 / 17.3 150
1,814 / 4,000 3.1 / 10.3 240
2,722 / 6,000 2.0 / 6.6 300

Line Pull and Rope Capacity:
